DJ-300 Glue Dispensing Robot

,

DJ-300 Glue Dispensing Robot

● Model: MARK DJ-300
● MOQ:  1set
● Packing details:  1 set / carton

Glue Dispensing Robot

Our glue dispensing robot has high performance and cost-effective platform, the working process is flexible and fast. The dispensing velocity, time, angles and dispensing volume, etc can be control as desired. It is suitable for various glue dispensing control, replace the manual dispensing operation, to realize the automatic dispensing, it improves the production efficiency, stable quality, and keep the dispensing process consistency. It can repid recovery cost.

Specifications:

Model DJ-300
Voltage 110V / 220V AC
Drive Mode 4-Axis precision step motor
Operating Range (X * Y * Z) 300 x 300 x 80mm
Movement Speed X * Y Axis: 0.1~800mm/sec, Z Axis :0.1~400mm/sec
Repeatability  Accuracy ±0.002mm (X * Y * Z)
Minimum Analysis 0.01mm (X * Y * Z)
Maximum Load Weight 8kgs (for work platform)
Program Capacity Max 255 Programs
Operate Temperature 10℃~40℃
Operate Humidity 20~90%
External Dimensions 650mm x 630mm x 680mm
Weight about 60kgs

Features:

1.Replace the human labor and save labor cost.
2.Simple and convenient operation, high speed and precise control.
3.Realize the precise dispensing by the high-precision motor.
4.High performance Linear structure platform with nice appearance.
